Pass Box
Brand:
Kazkaz Technologies
Product origin CHINA
Delivery time Within 7 days
Supply capacity Factory Direct Supply
Model ASPB-01 ASPB-02 ASPB-03 PB-01 PB-02 PB-03
Introduction:
Pass box is used to transfer goods between rooms of different clean levels of clean room. It can reduce times of opening door, prevent the air convection between different rooms and minimize the pollution extent.
Technical Parameters:
| Type | Air Shower Pass Box | Pass Box | ||||
| Model | ASPB-01 | ASPB-02 | ASPB-03 | PB-01 | PB-02 | PB-03 |
| External Size (W*D*H) mm | 660*570*1000 | 760*670*1100 | 860*770*1200 | 660*570*580 | 760*670*680 | 860*770*780 |
| Internal Size (W*D*H) mm | 500*500*500 | 600*600*600 | 700*700*700 | 500*500*500 | 600*600*600 | 700*700*700 |
| Material | 304 stainless steel | |||||
| Interlock | Electronical | |||||
| UV Lamp | 8W*1 | |||||
| HEPA Filter | Efficiency ≥99.995% at 0.3μm | / | ||||
| Clean Air Speed | 0.36~0.54m/s | / | ||||
| Power Supply | 220V, 50Hz; 110V, 50/60Hz | |||||
| Gross Weight(Kg) | 80 | 100 | 120 | 55 | 70 | 90 |
| Packing Size(W*D*H)mm | 780*700*1250 | 880*800*1350 | 980*900*1450 | 780*700*770 | 880*800*870 | 980*900*970 |
